Mobile Concrete Batching Plant

MOBILE CONCRETE BATCHING PLANT

Mobile concrete batching plants are perfectly adapted to short-term projects and frequent location changes. Its biggest advantage is that it can be easily installed in just 2-3 days with a minimum concrete foundation. Constructed on a wheeled, towable chassis for maximum mobility and quick setup. Mobile concrete batching plants are designed for a clear target; make a profitable investment for your business in terms of efficiency and sustainability. It provides an uninterrupted and trouble-free operation with minimum maintenance requirement.

You can contact us for new and/or used (second hand) mobile concrete batching plant models that you need.

DISTINCTIVE FEATURES

Minimizes operating costs thanks to the minimum need for foundation concrete in the area where it will be installed,
Only one tractor can be transported. Two axles are used to ensure safe weight distribution.
Robust and durable main chassis; It provides precise weighing by minimizing vibrations in long-lasting operation and measurements.
The main chassis is foldable in itself to ensure fast assembly and disassembly. The first concrete can be produced in 2-3 days.

OPTIONAL ITEMS

🔸 Mobile aggregate pre-feeding system

🔸 Mobile cement silo

🔸 Steel construction curtain wall

🔸 Insulated or non-insulated coating according to climatic conditions

🔸 Cooling systems (Chiller)

🔸 Heating systems (Steam Generator, Resistance System)

SPECIFICATIONS	MOB 30	MOB 60	MOB 100	MOB 120
Hourly Production Capacity	25 - 30 m³/h	50 - 60 m³/h	90 - 100 m³/h	110-120 m³/h
Mixer Capacity	0,5 m³ (750/500 L)	1,0 m³ (1500/1000 L)	2,0 m³ (3000/2000 L)	3,0 m³ (4500/3000 L)
Mixer Type	Planetary	Single-shaft	Twin-shaft	Twin-shaft
Mixer Motor Power	1 x 22 kW	1 x 37 kW	2 x 37 kW	2 x 55 kW
Aggregate Bunker Capacity	32 m³ (4 x 8 m³)	46 m³ (4 x 11,5 m³)	60 m³ (4 x 15 m³)	100 m³ (4 x 25 m³)
Aggregate Weighing Belt	0-1100 kg	0-2200 kg	0-4400 kg	0-6600 kg
Conveyor Belt	10x600x12.000 mm	10x800x12.000 mm	10x1000x12.700 mm	10x1000x12.850 mm
Cement Weighing Hopper	300 kg	500 kg	1000 kg	1500 kg
Water Weighing Hopper	200 L	300 L	700 L	1000 L
Additive Weighing Hopper	20 L	20 L	50 L	50 L
Automation System	Schneider Siemens	Schneider Siemens	Schneider Siemens	Schneider Siemens
Total Motor Power	55 kW	64 kW	106 kW	145 kW
